Quick Details

  • Type: Operating Table
  • Power Source: Electricity
  • Brand Name: Ysenmed
  • Model Number: YSOT-2100B
  • Place of Origin: Guangdong, China (Mainland)
  • forward lean: 28°
  • width: 500±20mm
  • Lowest and highest table height: (750-1000) 50mm
  • Power: AC 220V10% 50Hz
  • The lowest custom height: 600mm
  • Input power: 500VA
  • Head board up/down: 90°
  • Kidney elevator: 100mm
  • lenth: 2150mm
  • Left/right lean: 18°

Packaging & Delivery

Packaging Details medical general surgical table/bed wooden case
Delivery Time 10-15 working days after payment

2017 surgical room advanced YSOT-2100B adjustable medical electric operating table

  general surgical table



Technical parameters



Length: 210050mm

Width: 500mm20mm

Lowest and highest table height: (750-1000) 50mm

forward lean: 28

backward lean: 18

Table longitudinal scope: 40050mm

Left/right lean: 18

Leg Board down: 90

Leg evagination: 90

Back board up: 80

Head board up/down: 90

Kidney Elevator: 100mm

Power: AC 220V10% 50Hz

Input power: 500VA



Main Feature



1. Concise design: totally enclosed appearance, Ultra Thin table board, lifting column, base

and flanks frames, provide much space for C-arm, load bearing is 160kg



2. Longitudinal movement: Longitudinal slide way can make the operation table longitudinal

move, C-arm, X-ray and other imaging equipment can transilluminate the patient without

moving them.



3. 5 section operation table board: head board, back board, kidney elevator, hip board and

leg board.



4. X-ray transillumination: table board made by polymer polymerization material, supporting

taking photo by C-arm and X-ray. X-ray cassette can be loaded through X-ray cassette

slideway.



5. Square lifting column is made by Germany, which has 4 times safety factor and 8 fasteners

which can make it stable



6. Antiseptic surface: base, lifting column sleeve is made by wiredrawing stainless steel,

elegant appearance, antiseptic, antirust, easy for clean and disinfection.



7. Computer control: using microcomputer hand control adjusts the relative operation position.

Picture printed on the button indicates the function, easy to understand and has long life



8. The operation table has excellent function, elegant appearance, easy to operate. The

memory mattress, thickness is 70mm, effectively relieve patients pressure point, prevent

postoperative bedsore occurred



9. Machine design is in line with IEC60601-2-46, different accessories can be configured to

suit the different needs of surgery








general surgical table

general surgical table
electrical operating table electric operation room table medical operation theatre bed
