3.5kw digital medical mobile xray x-ray c-arm

FOB Reference Price:Get Latest Price
$27,500.00 - $31,500.00 / Sets | 1 Set/Sets c-arm (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Properties:
Medical X-ray Equipments & Accessories
Brand Name:
YENMED
Model Number:
YSX-C35D
Place of Origin:
Guangdong, China
mAs:
1mA.s-250mA.S
Medical X-Ray Machine NO.:
YSX-C35D
Printer:
Printer Laser / jet Printer
style:
DR
x-ray:
3.5kw
detetor:
CCD
Supply Ability
Supply Ability:
100 Set/Sets per Month c-arm
Packaging & Delivery
Packaging Details
double export standard packing of c-arm xray
Port
Guangzhou port
Lead Time :
Within 15 working days after payment

3.5kw digital medical mobile c-arm x-ray

YSX-C35D









Technical parameters and configuration:



Main components

Technique parameter



IMD X-ray tube

Model: YSX-C35D

Model: YSX-C50D



Power:3.5kW

Power:5.0kW



Double focus fixed anode focus:1.5mm / 0.6mm

Double focus rotational anode focus: 0.3mm / 0.6mm



Anode Heat Capacity:40kHu X-ray tube sleeve heat capacity:667kHu

Anode Heat Capacity:200kHu X-ray tube sleeve heat capacity:800kHu



High Voltage X-ray Generator

Working frequency:40kHz



Image intensifier

Toshiba 9"(including 3 fields of view 4.5"/ 6"/9")



Tube voltage

Fluoroscopy Radiograph:40kV-110kV

Fluoroscopy Radiograph:40kV-120kV



Tube current

Fluoroscopy: 0.5-4mA Enhanced Automatic Fluoroscopy: 1mA-8mA   Pulse Fluoroscopy :2pps;8mA



mAs

1mA.s-250mA.S



Fluoroscopy mode

Manual Fluoroscopy; Semi-Automatic Fluoroscopy;Automatic Fluoroscopy; Enhanced Automatic Fluoroscopy; Pulse Fluoroscopy



Intelligent exposure control

No matter the object is in the center or on the fringing field of the image intensifier, the images are the same. The exposure dose is reduced.



Iris beam limiting device

when not exposure, keep in the state of Iris Beam limiting preview ,when exposure,keep blanking cycle track




General radiography

40kV-120kV;1.0mA.s-250mA.s

step length 1 kV;1.0mA.s



Digital radiography (digital spot film)

40kV-120kV;Max 16mA

Common screen film radiography is eliminated. Digital radiography can get better images









  c-arm



  c-arm

  c-arm

  c-arm

  c-arm



  c-arm
